Description
MODELS | VLT - Z12050 | VLT - E12035 |
Round Tube Diameter | Φ 20 - Φ 500 (mm) | Φ 10 - Φ 350 (mm) |
Square Tube Diameter | 20 - 350 ( mm) | 10 - 350 ( mm) |
Cutting Length | 12500mm | 12500mm |
Laser source | Max / IPG / Raycus | Max / IPG / Raycus |
Power capacity | 3000/6000/12000… (W) | 3000/6000/12000… (W) |
Wavelength | 1070 – 1080 (nm) | 1070 – 1080 (nm) |
CNC Control System | FSCUT5000A | FSCUT5000A |
Servo Motor | Yaskawa / Inovance | Yaskawa / Inovance |
Laser cutting head | Raytools (Switzerland) / BOCI (China) | Raytools (Switzerland) / BOCI (China) |
Maximum movement speed | 50 (r/min) | 60 (r/min) |
Positioning Accuracy | ± 0.05 (mm) | ± 0.05 (mm) |
Repeatability | 0.05 (mm) | 0.05 (mm) |
Power supply | 380V, 3 phase, 50HZ, 50A | 380V, 3 phase, 50HZ, 50A |
